Isobar MT050-PU8
Intended primarily as a sound barrier for cab floors. Acoustical insulation in laminated mat form consisting of a 5 Kg/m² barrier and a layer of 8 mm acoustical PU foam. Embossed black facing. Fuel, oil and water resistant. Total weight : 5 Kg/m².
Application
Isobar MT050-PU8 is designed for use as a hanging barrier or other applications where a self-supporting barrier is required. This is very high in mass and is effective in reducing noise transmission of a very broad band of frequencies, including very low frequencies. It is composed of rugged vinyl wear surface on one side of a dense PVC barrier.
Twist grain wear surface
| Charateristic | Typical value |
|---|---|
| Type | Vinyl |
| Pattern | Twist grain |
| Backing | Reinforced |
| Total Weight | 0.80 kg/m² |
| Color | Standard: Black (On demand: Mojave, Grey, Tan) |
Composite
| Charateristic | Typical value |
|---|---|
| Lamination of layers | Thermal bond – No adhesives |
| Peel strenght between layers | 700 g/in (ASTM D 903 Mod) (or material destruction) |
| Flammability | FMVSS 302 – Pass |
| Total Weight | 5 kg/m² |
PVC Barrier
| Charateristic | Typical value |
|---|---|
| Type | PVC |
| Specific gravity | 2.5 |
| Flexibility | very limp |
Transmission loss
| Freq. | 125Hz | 250Hz | 500Hz | 1000Hz | 2000Hz | 4000Hz |
|---|---|---|---|---|---|---|
| Decoupler: 8 mm PU* | 15 | 20 | 27 | 47 | 64 | 77 |
**on 16 gauge steel per SAE J-1400*
